HANDI FIT FIRE RATED JUNCTION BOX
CCG - Ex Junction Boxes
- 0800 442 182
- +64 9 274 3340 (NZ)
- 100% NZ Owned & Operated
Description
FEATURES & BENEFITS
- Handi-FitTM Fire Rated Box for emergency circuits (950oC for 3-hours).
- Screw-on lid provides ease of installation. Lid locking with a special key prevents unauthorized tampering.
- Supplied complete with safety securing lid lanyard.
- Raised domed lid facilitates connections to be made outside of the box.
- Only approved CCG cable glands and terminals must be used.
- No exposed metal parts.
- Dust and waterproof to IP66/68 when used with CCG sealed cable glands.
- No drilling or tapping of cable entries required.
- Mounting studs provided for DIN rail if using Terminal Blocks.
- DIN Rail mounting studs are provided for use with terminal blocks.
- Internal earthing to all entries and rail provided.
- Type:
- Handi FitTM 4-Way Fire Rated Junction Box
- Handi FitTM Y Fire Rated Junction Box
- Handi FitTM H Fire Rated Junction Box - Optional Accessories:
- Ceramic Terminals, Insulated Connectors, PTFE Washers, Box Spanner (Lid Locking Key).
- 4-Blanking plugs are provided - Box Material:
- Impact, corrosion and UV resistant glass reinforced polyester compound
